Affordable Bioprinting Technology: A New Era

Affordable Bioprinting: Tissue at the Push of a Button

In the realm of modern medicine and pharmacology, the ability to create artificial, functional tissue holds immense promise. From cartilage and bone to muscle tissue, the potential applications are vast. Yet, the journey from concept to reality is fraught with challenges. As Benedikt Kaufmann, a bioengineer at the Centrum für Angewandtes Tissue Engineering und Regenerative Medizin (CANTER) at the Hochschule München, asserts, "Tissue engineering is a technology of the future." Despite the strides made in 3D printing techniques for organic structures, the goal of producing customized tissue on a larger scale remains elusive. The key to advancing tissue engineering lies in global collaboration, knowledge generation, and sharing.

The Financial Barrier in Bioprinting

One of the most significant hurdles in the field is the prohibitive cost of bioprinters. These machines, essential for creating three-dimensional cell structures, often come with a price tag of tens of thousands of euros. For smaller labs or institutions, this cost is simply unmanageable. However, Kaufmann, during his doctoral research, has pioneered a cost-effective alternative. By modifying a standard 3D printer, typically used for plastic prototypes, he has developed a method to print living tissue. This innovation, achieved in collaboration with an interdisciplinary team at CANTER and the Technical University of Munich, is now accessible to all through an open-source blueprint.

Creating the Perfect Environment

The challenge of affordable bioprinting technology lies not just in the machinery but in creating the right conditions for cell and protein processing. As Kaufmann recalls, "The biggest challenge was creating suitable environmental conditions." The process requires a consistent temperature of 37 degrees Celsius and high humidity. The team ingeniously used heating foils attached to the printer's aluminum casing, controlled by a microcontroller, to maintain the necessary temperature. Humidity levels exceeding 90% were achieved using water-soaked cellulose. Additionally, the team replaced the printer's metal platform with a glass plate, allowing for direct printing of biomaterials and cells, which can then be examined under a microscope.

Innovative Printing Techniques

The modified printer employs masked stereolithography, a cell-friendly technique. Light from LEDs is projected through a liquid crystal display onto a gelatinous hydrogel-coated glass plate. This method activates specific pixels, ensuring proteins in the hydrogel cross-link and harden precisely where needed, layer by layer, forming a three-dimensional structure.

Customizable Structures

Despite its small size, the modified 3D printer delivers results comparable to professional lab equipment. "Our experiments have shown that the modified 3D printer can produce organic scaffolds with varying stiffness," Kaufmann notes. This is crucial, as bone tissue requires greater hardness than muscle tissue. The team has also successfully integrated stem cells into the structures during the printing process.

Empowering Researchers Worldwide

For research teams previously unable to create tissue constructs, this development is groundbreaking. With the online blueprint, they can transform a simple commercial 3D printer into a bioprinter. "No engineering expertise is required," Kaufmann emphasizes. This opens the door for small labs to gain experience in creating, characterizing, and optimizing artificial tissue, fostering knowledge generation and sharing to advance tissue engineering. Even schools can use the modified printer to introduce students to 3D printing with biomaterials.

The Collaborative Project

This project was a collaborative effort led by Benedikt Kaufmann, alongside Matthias Rudolph, Markus Pechtl, Geronimo Wildenburg, Hauke Clausen-Schaumann, and Stefanie Sudhop from CANTER, Hochschule München. They were supported by Oliver Hayden from the Heinz Nixdorf Chair of Biomedical Electronics at the Technical University of Munich.

The Visionary Behind the Innovation

Benedikt Kaufmann has been a research associate at Hochschule München since 2018, pursuing a cooperative doctorate with the Technical University of Munich. He holds a Bachelor's degree in Bioengineering and a Master's in Micro and Nanotechnology from HM. His research focuses on advancing light-based bioprinting technologies and developing printable biomaterials with an emphasis on cell compatibility.

In conclusion, the advent of affordable bioprinting technology marks a significant milestone in tissue engineering. By democratizing access to bioprinting, researchers worldwide can now contribute to this burgeoning field, paving the way for innovations that could revolutionize medicine and pharmacology. As the technology continues to evolve, the possibilities for creating complex, functional tissues are boundless, promising a future where tissue engineering becomes an integral part of healthcare solutions.
